Description
MODELS
| Model # | Part # | Description |
| 270 | 10004733 | 270 Coupling & 271 Thimble |
| 270A | 10004735 | 270 Coupling, 501 Bolt Kit, 281 Air Chamber, 267 Air Chamber Adapter Bracket, 10000107 271 |
| 270A-2 | 10004736 | Same as 270A, without the 501 Bolt Kit |
| 270AF | 10004738 | Same as 270A, with 267F Air Chamber Adapter Bracket instead of 267 |
| 270A-267H | 10004737 | Same as 270A, with 267H Air Chamber Adapter Bracket instead of 267 |
KIT COMPONENTS & ACCESSORY PARTS
| Model # | Part # | Description |
| 271 | 10000107 | Thimble |
| 501 | 10000149 | Bolt Kit |
| 281 | 10000116 | Air Chamber, Type 24 |
| 282 | 10000122 | Air Chamber, Type 30 |
| 267 | 10000098 | Air Chamber Adapter Bracket (2 3/4 in. overall length) |
| 267F | 10000101 | Air Chamber Adapter Bracket (4 5/8 in. overall length) |
| 267H | 10000102 | Air Chamber Adapter Bracket (3/4 in. overall length) |
| 270PK | 10000292 | Parts Kit |
| 279PK | 10000315 | Parts Kit (for 279 Shoe) |
| 378M | 10004767 | Drawbar Guide Set (Left & Right Sides Incl.) |
| 378ML | 10000126 | Drawbar Guide, Left Side Only |
| 378MR | 10000127 | Drawbar Guide, Right Side Only |
| 14011 | 10000059 | Wear Gage |
| 14026 | 10000071 | Wear Gage, Latch Gage Bar |
SPECIFICATIONS
| Maximum Gross Trailer Weight | 90,000 lbs. (40,823 kg) | |
| Maximum Tongue Weight | 18,000 lbs. (8,165 kg) | |
| Ultimate Latch Capacity | 12,000 lbs. (5,443 kg) | |
| Maximum Eye X-Section | 1 13/16 in. (46 mm) | |
| Minimum Eye Opening | 2 3/8 in. (60 mm) | |
| Unit Weight | 26.3 lbs. (11.9 kg) |
-
